Technical Sheet

2020 Ford F-150 XLT 4WD Reg Cab 6.5' Box

4WD Standard Pickup Trucks
Power   3.3 L
Engine   Regular Unleaded V-6
Transmission   Automatic w/OD
Fuel(L/100KM)   City : N/A / Highway : N/A
Seats   2
  • Emissions
    • G/km Of CO2 Emissions  N/A
    • Kg/yr of CO2 Emissions @ 20K km/year  N/A
  • Weight Information
    • Standard Weight - Front (lbs)0
    • Standard Weight - Rear (lbs)0
    • Gross Axle Wt Rating - Front (lbs)3000
    • Gross Axle Wt Rating - Rear (lbs)3350
    • Curb Weight - Front (lbs)2585
    • Curb Weight - Rear (lbs)1758
    • Option Weight - Front (lbs)6.00
    • Option Weight - Rear (lbs)5.00
    • Reserve Axle Capacity - Front (lbs)409.00
    • Reserve Axle Capacity - Rear (lbs)1587.00
    • As Spec'd Curb Weight (lbs)4354.00
    • As Spec'd Payload (lbs)1766.00
    • Maximum Payload Capacity (lbs)1777.00
    • Gross Combined Wt Rating (lbs)9800
    • Gross Axle Weight Rating (lbs)6350.00
    • Curb Weight (lbs)4343.00
    • Reserve Axle Capacity (lbs)1996.00
    • Total Option Weight (lbs)11.00
    • Payload Weight Front (lbs)0
    • Payload Weight Rear (lbs)0
    • Gross Vehicle Weight Rating (lbs)6120.00
  • Transmission
    • Drivetrain  Four Wheel Drive
    • Trans Order Code  446
    • Trans Type  6
    • Trans Description Cont.  Automatic w/OD
    • First Gear Ratio (:1)  4.17
    • Second Gear Ratio (:1)  2.34
    • Third Gear Ratio (:1)  1.52
    • Fourth Gear Ratio (:1)  1.14
    • Fifth Gear Ratio (:1)  0.86
    • Sixth Gear Ratio (:1)  0.69
    • Reverse Ratio (:1)  3.40
    • Clutch Size (in)N/A
    • Trans Power Take Off  N/A
    • Final Drive Axle Ratio (:1)  N/A
    • Transfer Case Model  Electronic
    • Transfer Case Gear Ratio (:1), High  N/A
    • Transfer Case Gear Ratio (:1), Low  N/A
    • Transfer Case Power Take Off  No
  • Interior Dimensions
    • Passenger Capacity  3
    • Front Head Room (in)40.8
    • Front Leg Room (in)43.9
    • Front Shoulder Room (in)66.7
    • Front Hip Room (in)62.5
    • Second Head Room (in)N/A
    • Second Leg Room (in)N/A
    • Second Shoulder Room (in)N/A
    • Second Hip Room (in)N/A
  • Mileage
    • EnerGuide Estimate - City (L/100 km)N/A
    • EnerGuide Estimate - Hwy (L/100 km)N/A
    • Cruising Range - City (mi)N/A
    • Cruising Range - Hwy (mi)N/A
  • Trailering
    • Dead Weight Hitch - Max Trailer Wt. (lbs)5000
    • Dead Weight Hitch - Max Tongue Wt. (lbs)500
    • Wt Distributing Hitch - Max Trailer Wt. (lbs)5000
    • Wt Distributing Hitch - Max Tongue Wt. (lbs)500
    • Maximum Trailering Capacity (lbs)5000
  • Engine
    • Engine Order Code  99B
    • Engine Type  Regular Unleaded V-6
    • Displacement  3.3 L
    • Fuel System  Port/Direct Injection
    • SAE Net Horsepower @ RPM  290 @ 6500
    • SAE Net Torque @ RPM  265 @ 4000
    • Engine Oil Cooler  None
  • Electrical
    • Cold Cranking Amps @ 0° F (Primary)  610
    • Cold Cranking Amps @ 0° F (2nd)  610
    • Maximum Alternator Capacity (amps)  200
    • Cold Cranking Amps @ 0° F (3rd)  N/A
  • Frame
    • Frame Type  N/A
    • Sect Modulus Rails Only (in³)N/A
    • Frame RBM (N/A)N/A
    • Frame Strength (lbs)N/A
    • Frame Thickness (in)N/A
  • Suspension
    • Suspension Type - Front  Double Wishbone
    • Suspension Type - Rear  Leaf
    • Spring Capacity - Front (lbs)3000
    • Spring Capacity - Rear (lbs)3350
    • Axle Type - Front  Independent
    • Axle Type - Rear  Rigid Axle
    • Axle Capacity - Front (lbs)3750
    • Axle Capacity - Rear (lbs)4800
    • Axle Ratio (:1) - Front  3.55
    • Axle Ratio (:1) - Rear  3.55
    • Shock Absorber Diameter - Front (mm)N/A
    • Shock Absorber Diameter - Rear (mm)N/A
    • Stabilizer Bar Diameter - Front (in)N/A
    • Stabilizer Bar Diameter - Rear (in)N/A
  • Tires
    • Front Tire Order Code  T74
    • Rear Tire Order Code  T74
    • Front Tire Size  P265/70SR17
    • Rear Tire Size  P265/70SR17
    • Spare Tire Size  Full-Size
    • Front Tire Capacity (lbs)3650
    • Rear Tire Capacity (lbs)4056
    • Spare Tire Capacity (lbs)N/A
    • Revolutions/Mile @ 45 mph - Front (Rev/Mile)N/A
    • Revolutions/Mile @ 45 mph - Rear (Rev/Mile)N/A
    • Revolutions/Mile @ 45 mph - Spare (Rev/Mile)N/A
  • Wheels
    • Front Wheel Size (in)17 X 7.5
    • Rear Wheel Size (in)17 X 7.5
    • Spare Wheel Size (in)Full-Size
    • Front Wheel Material  Aluminum
    • Rear Wheel Material  Aluminum
    • Spare Wheel Material  Steel
  • Steering
    • Steering Type  Rack-Pinion
    • Steering Ratio (:1), On Centre  N/A
    • Steering Ratio (:1), At Lock  N/A
    • Turning Diameter - Curb to Curb (ft)40.7
    • Turning Diameter - Wall to Wall (ft)N/A
  • Brakes
    • Brake Type  4-Wheel Disc
    • Brake ABS System  4-Wheel
    • Brake ABS System (Second Line)  4-Wheel
    • Disc - Front (Yes or )  Yes
    • Disc - Rear (Yes or )  Yes
    • Front Brake Rotor Diam x Thickness (in)13.8
    • Rear Brake Rotor Diam x Thickness (in)13.7
  • Fuel Tank
    • Fuel Tank Capacity, Approx (L)87.1
    • Aux Fuel Tank Capacity, Approx (L)N/A
    • Fuel Tank Location  N/A
    • Aux Fuel Tank Location  N/A
  • Exterior Dimensions
    • Wheelbase (in)122
    • Length, Overall w/o rear bumper (in)209.3
    • Length, Overall (in)N/A
    • Width, Max w/o mirrors (in)79.9
    • Height, Overall (in)76.9
    • Overhang, Front (in)37.8
    • Overhang, Rear w/o bumper (in)N/A
    • Front Bumper to Back of Cab (in)N/A
    • Cab to Axle (in)N/A
    • Cab to End of Frame (in)N/A
    • Ground to Top of Load Floor (in)34.8
    • Ground to Top of Frame (in)N/A
    • Frame Width, Rear (in)N/A
    • Ground Clearance, Front (in)9.4
    • Ground Clearance, Rear (in)9.4
    • Body Length (ft)0.00
    • Cab to Body (in)N/A
  • Cargo Area Dimensions
    • Cargo Box Length @ Floor (in)78
    • Cargo Box Width @ Top, Rear (in)65.2
    • Cargo Box Width @ Floor (in)65.2
    • Cargo Box Width @ Wheelhousings (in)50.6
    • Cargo Box (Area) Height (in)21.4
    • Tailgate Width (in)60.3
    • Cargo Volume (ft³)62.3
    • Ext'd Cab Cargo Volume (ft³)N/A
  • Mechanical
    • Engine: 3.3L V6 PDFI -inc: auto start/stop technology and flex-fuel capability
    • Transmission: Electronic 6-Speed Automatic -inc: selectable drive modes: normal/tow-haul/sport
    • 3.55 Axle Ratio
    • GVWR: 2,776 kg (6,120 lb) Payload Package
    • Transmission w/SelectShift Sequential Shift Control
    • Electronic Transfer Case
    • Part-Time Four-Wheel Drive
    • Block Heater
    • 70-Amp/Hr 610CCA Maintenance-Free Battery w/Run Down Protection
    • 200 Amp Alternator
    • Towing Equipment -inc: Trailer Sway Control
    • Trailer Wiring Harness
    • 785kg Maximum Payload
    • Gas-Pressurized Shock Absorbers
    • Front Anti-Roll Bar
    • Electric Power-Assist Speed-Sensing Steering
    • 87.1 L Fuel Tank
    • Single Stainless Steel Exhaust
    • Auto Locking Hubs
    • Double Wishbone Front Suspension w/Coil Springs
    • Leaf Rear Suspension w/Leaf Springs
    • 4-Wheel Disc Brakes w/4-Wheel ABS, Front And Rear Vented Discs, Brake Assist, Hill Hold Control and Electric Parking Brake
  • Exterior
    • Wheels: 17" Silver Painted Aluminum
    • Tires: P265/70R17 OWL A/T
    • Regular Box Style
    • Steel Spare Wheel
    • Full-Size Spare Tire Stored Underbody w/Crankdown
    • Clearcoat Paint
    • Chrome Rear Step Bumper
    • Chrome Front Bumper w/Body-Coloured Rub Strip/Fascia Accent and 2 Tow Hooks
    • Black Side Windows Trim and Black Front Windshield Trim
    • Black Door Handles
    • Black Power Side Mirrors w/Convex Spotter and Manual Folding
    • Fixed Rear Window
    • Variable Intermittent Wipers
    • Deep Tinted Glass
    • Aluminum Panels
    • Chrome Grille
    • Tailgate Rear Cargo Access
    • Tailgate/Rear Door Lock Included w/Power Door Locks
    • Cargo Lamp w/High Mount Stop Light
    • Fully Automatic Aero-Composite Halogen Auto High-Beam Headlamps w/Delay-Off
    • Front Fog Lamps
    • Perimeter/Approach Lights
  • Entertainment
    • Radio: AM/FM SiriusXM Satellite -inc: clock and 5 speakers
    • Radio w/Seek-Scan, Speed Compensated Volume Control, Radio Data System and External Memory Control
    • Fixed Antenna
  • Interior
    • Cloth 40/20/40 Front Seat -inc: folding armrest, cupholders, storage and manual driver/passenger lumbar
    • 4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement
    • 4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement
    • Manual Tilt/Telescoping Steering Column
    • Gauges -inc: Speedometer, Odometer, Voltmeter, Oil Pressure, Engine Coolant Temp, Tachometer, Transmission Fluid Temp and Trip Odometer
    • FordPass Connect 4G LTE WiFi Mobile Hotspot Internet Access
    • Front Cupholder
    • Front Cigar Lighter(s)
    • Compass
    • Keypad
    • Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry and Panic Button
    • Cruise Control w/Steering Wheel Controls
    • Manual Air Conditioning
    • Glove Box
    • Full Cloth Headliner
    • Urethane Gear Shift Knob
    • Interior Trim -inc: Metal-Look Instrument Panel Insert, Cabback Insulator and Chrome Interior Accents
    • Day-Night Rearview Mirror
    • Driver And Passenger Visor Vanity Mirrors
    • 2 12V DC Power Outlets
    • Front Map Lights
    • Fade-To-Off Interior Lighting
    • Full Carpet Floor Covering -inc: Carpet Front Floor Mats
    • Pickup Cargo Box Lights
    • Smart Device Remote Engine Start
    • SYNC 3 -inc: Enhanced Voice Recognition Communications and Entertainment System w/911 Assist and AppLink, 8" LCD touchscreen in centre stack w/swiping and pinch-to-zoom capabilities, compass and clock display, Apple CarPlay, Android Auto and media hub w/2 smart charging USB ports
    • Instrument Panel Bin, Dashboard Storage, Driver And Passenger Door Bins and 1st Row Underseat Storage
    • Power 1st Row Windows w/Driver And Passenger 1-Touch Up/Down
    • Delayed Accessory Power
    • Power Door Locks w/Autolock Feature
    • Outside Temp Gauge
    • Analog Display
    • 2 Seatback Storage Pockets
    • Securilock Anti-Theft Ignition (pats) Engine Immobilizer
    • Perimeter Alarm
  • Safety
    • Electronic Stability Control (ESC) And Roll Stability Control (RSC)
    • ABS And Driveline Traction Control
    • Side Impact Beams
    • Dual Stage Driver And Passenger Seat-Mounted Side Airbags
    • Ford Co-Pilot360 - Pre-Collision Assist with Automatic Emergency Braking (AEB)
    • Tire Specific Low Tire Pressure Warning
    • Dual Stage Driver And Passenger Front Airbags
    • Curtain 1st Row Airbags
    • Airbag Occupancy Sensor
    • Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters and Pretensioners
    • Restricted Driving Mode
    • Back-Up Camera
Exterior colourInterior colour
Oxford White (YZ)Medium Earth Grey
Magnetic (J7)Medium Light Camel, Medium Earth Grey
Rapid Red Metallic Tinted Clearcoat (D4)Medium Light Camel
Stone Grey (D1)Medium Earth Grey
Magma (E2)Medium Light Camel, Medium Earth Grey
Agate Black (UM)Medium Light Camel, Medium Earth Grey
